Liora

$100.00

Liora downlight collection offers multiple options to choose from wattages ranging between 5W – 25W in all standard symmetric beam options and as made available across 3 varied size options to adopt to site requirements within the standard color spectrum. CCT of 5000K and 6000K are also available on request. Standard protocol for fixed output driver is offered in our article coding. Dimmable driver options are available on request.



Technical Data

IP RateIP20
Beam Angle15° , 24° , 38°
CRI>80 , >90
LEDCOB
LED DriverLifud Eaglerise Aidimming Other customized brands
Input VoltageAC220V-240V 50-60Hz
FinishWhite
Black



Certifications



SKU: N/A Category:

Available Options

CODEPOWER
(w)		LUMEN OUTPUT
(±5%, lm)		DIMENSION
(mm)		CUT OUT
(mm)		BEAM ANGLECCTFINISH
AE-RS05021-55400Φ 65x60Φ 5515° / 24° / 38°2700K
3000K
4000K
5000K
6000K
White/Black
AE-RS05021-77560Φ 65x60Φ 5515° / 24° / 38°
White/Black
AE-RS05021-1010800Φ 85x76Φ 7515° / 24° / 38°
White/Black
AE-RS05021-1212960Φ 85x76Φ 7515° / 24° / 38°
White/Black
AE-RS05021-20201600Φ 105x108Φ 9515° / 24° / 38°
White/Black
AE-RS05021-25252000Φ 105x108Φ 9515° / 24° / 38°
White/Black
Wattage

12, 10, 20, 25, 5, 7
Color Temperature

2700, 3000, 4000, 5000, 6000
Beam Angle

15, 24, 38
Product Code

AE-RS05021-5, AE-RS05021-7, AE-RS05021-10, AE-RS05021-12, AE-RS05021-20, AE-RS05021-25
