Liova

$100.00

Liova downlight collection offers multiple options to choose from wattages ranging between 7W – 18W in all standard symmetric beam options and as made available across 3 varied size options to adopt to site requirements within the standard color spectrum. CCT of 5000K and 6000K are also available on request. Standard protocol for fixed output driver is offered in our article coding. Dimmable driver options are available on request.



Technical Data

IP RateIP20
Beam Angle15°, 24°, 36°, 55°
CRI>80 , >90
LEDCOB
LED DriverLifud Eaglerise Aidimming Other customized brands
Input VoltageAC220V-240V 50-60Hz
FinishGlossy black, Glossy White, Glossy SILVER, Matt Silver



Certifications



SKU: N/A Category:

Available Options

CODEPOWER
(w)		LUMEN OUTPUT
(±5%, lm)		DIMENSION
(mm)		CUT OUT
(mm)		BEAM ANGLECCTFINISH
AE-RS05028-77525Φ 63x52Φ 5515° / 24° / 36° / 55°2700K
3000K
4000K
5000K
6000K
Glossyblack/GlossyWhite/GlossySILVER/MattSilver
AE-RS05028-1010750Φ 85x64Φ 7515° / 24° / 36° / 55°
Glossyblack/GlossyWhite/GlossySILVER/MattSilver
AE-RS05028-15151125Φ 102x74Φ 9015° / 24° / 36° / 55°
Glossyblack/GlossyWhite/GlossySILVER/MattSilver
AE-RS05028-18181350Φ 102x74Φ 9015° / 24° / 36° / 55°
Glossyblack/GlossyWhite/GlossySILVER/MattSilver
Wattage

18, 10, 15, 7
Color Temperature

2700, 3000, 4000, 5000, 6000
Beam Angle

15, 24, 36, 55
Product Code

AE-RS05028-7, AE-RS05028-10, AE-RS05028-15, AE-RS05028-18
