Lioze

$100.00

Lioze downlight collection offers multiple options to choose from wattages ranging between 10W – 60W in all standard symmetric beam options and as made available across 7 varied size options to adopt to site requirements within the standard color spectrum. CCT of 5000K and 6000K are also available on request. Standard protocol for fixed output driver is offered in our article coding. Dimmable driver options are available on request.



Technical Data

IP RateIP20
Beam Angle15° , 24° , 36° , 60°
CRI>80 , >90
LEDCOB
LED DriverLifud Eaglerise Aidimming Other customized brands
Input VoltageAC220V-240V 50-60Hz
FinishBlack, White, Matt silver, Matt black, Glossy Black, Glossy silver, champagne gold, Rose gold



Certifications



SKU: N/A Category:

Available Options

CODEPOWER
(w)		LUMEN OUTPUT
(±5%, lm)		DIMENSION
(mm)		CUT OUT
(mm)		BEAM ANGLECCTFINISH
AE-RS05029-1010800Φ 90x65Φ 75-8015° / 24° / 36° / 60°2700K
3000K
4000K
5000K
6000K
BlackWhiteMattsilverMattblackGlossyBlackGlossysilverchampagnegoldRosegold
AE-RS05029-1212960Φ 90x65Φ 75-8015° / 24° / 36° / 60°
BlackWhiteMattsilverMattblackGlossyBlackGlossysilverchampagnegoldRosegold
AE-RS05029-15151200Φ 95x60Φ 8015° / 24° / 36° / 60°
BlackWhiteMattsilverMattblackGlossyBlackGlossysilverchampagnegoldRosegold
AE-RS05029-15B151200Φ 105x64Φ 9515° / 24° / 36° / 60°
BlackWhiteMattsilverMattblackGlossyBlackGlossysilverchampagnegoldRosegold
AE-RS05029-18181440Φ 105x64Φ 9515° / 24° / 36° / 60°
BlackWhiteMattsilverMattblackGlossyBlackGlossysilverchampagnegoldRosegold
AE-RS05029-20201600Φ 130x72Φ 12015° / 24° / 36° / 60°
BlackWhiteMattsilverMattblackGlossyBlackGlossysilverchampagnegoldRosegold
AE-RS05029-30302400Φ 160x82Φ 14515° / 24° / 36° / 60°
BlackWhiteMattsilverMattblackGlossyBlackGlossysilverchampagnegoldRosegold
AE-RS05029-35352800Φ 160x82Φ 14515° / 24° / 36° / 60°
BlackWhiteMattsilverMattblackGlossyBlackGlossysilverchampagnegoldRosegold
AE-RS05029-40403200Φ 180x90Φ 16015° / 24° / 36° / 60°
BlackWhiteMattsilverMattblackGlossyBlackGlossysilverchampagnegoldRosegold
AE-RS05029-45453600Φ 180x90Φ 16015° / 24° / 36° / 60°
BlackWhiteMattsilverMattblackGlossyBlackGlossysilverchampagnegoldRosegold
AE-RS05029-50504000Φ 230x100Φ 20015° / 24° / 36° / 60°
BlackWhiteMattsilverMattblackGlossyBlackGlossysilverchampagnegoldRosegold
AE-RS05029-60604800Φ 230x100Φ 20015° / 24° / 36° / 60°
BlackWhiteMattsilverMattblackGlossyBlackGlossysilverchampagnegoldRosegold
Wattage

12, 18, 10, 15, 20, 30, 35, 40, 45, 50, 60
Color Temperature

2700, 3000, 4000, 5000, 6000
Beam Angle

15, 24, 36, 60
Product Code

AE-RS05029-10, AE-RS05029-12, AE-RS05029-15, AE-RS05029-15B, AE-RS05029-18, AE-RS05029-20, AE-RS05029-30, AE-RS05029-35, AE-RS05029-40, AE-RS05029-45, AE-RS05029-50, AE-RS05029-60
