Nura
Nura - Image 2
Nura - Image 3

Nura

$100.00

Squr adjustable downlight collection offers multiple options to choose from wattages ranging between 9W – 40W in all standard symmetric beam options and as made available across 4 varied size options to adopt to site requirements within the standard color spectrum. Special IP44 versions can also be offered on request. CCT of 5000K and 6000K are also available on request. Standard protocol for fixed output driver is offered in our article coding. Dimmable driver options are available on request.



Technical Data

IP RateIP20
Beam Angle15°, 24°, 38°
CRI>80 , >90
LEDCOB
Input VoltageAC220V-240V 50-60Hz
FinishWhite
Black
White +Black



Certifications



SKU: N/A Category:

Available Options

CODEPOWER
(w)		LUMEN OUTPUT
(±5%, lm)		DIMENSION
(mm)		CUT OUT
(mm)		BEAM ANGLECCTFINISH
AE-RS30047-55400Φ 70x58Φ 5515° / 24° / 38°2700K
3000K
4000K
5000K
6000K
White/Black/White+Black
AE-RS30047-77560Φ 70x70Φ 5515° / 24° / 38°
White/Black/White+Black
AE-RS30047-1010800Φ 90x72Φ 7515° / 24° / 38°
White/Black/White+Black
AE-RS30047-1212960Φ 90x75Φ 7515° / 24° / 38°
White/Black/White+Black
AE-RS30047-18181440Φ 112x92Φ 9515° / 24° / 38°
White/Black/White+Black
AE-RS30047-20201600Φ 112x95Φ 9515° / 24° / 38°
White/Black/White+Black
AE-RS30047-25252000Φ 112x95Φ 9515° / 24° / 38°
White/Black/White+Black
Wattage

12, 18, 10, 20, 25, 5, 7
Color Temperature

2700, 3000, 4000, 5000, 6000
Beam Angle

15, 24, 38
Product Code

AE-RS30047-5, AE-RS30047-7, AE-RS30047-10, AE-RS30047-12, AE-RS30047-18, AE-RS30047-20, AE-RS30047-25
